ASTM SA-36

Grade Introduction:

ASTM  SA-36 is the most commonly used mild and hot-rolled steel. It has excellent welding properties and is suitable for grinding, punching, tapping, drilling, and machining processes. The yield strength of ASTM  SA36 is less than that of cold roll C1018, thus enabling ASTM  SA36 to bend more readily than C1018. Normally, larger diameters in ASTM  SA36 are not produced since C1018 hot roll rounds are used.

Grade Application:

ASTM  SA36 steel has the following applications:

• It is used in bolted, riveted or welded construction of bridges, buildings and oil rigs.

• It is used in forming tanks, bins, bearing plates, fixtures, rings, templates, jigs, sprockets, cams, gears, base plates, forgings, ornamental works, stakes, brackets, automotive and agricultural equipment, frames, machinery parts.

• It is used for various parts obtained by flame cutting such as in parking garages, walkways, boat landing ramps and trenches.

Equivalent grades:

Standard – IS 2062 GR E250 , E350 , E410 AND E450 A / B / BO / BR, A36, etc

Addition to other grades:

MS, EN1A, EN3B, EN8, EN8D, EN9, EN19, EN24, EN31, EN32B, EN36C, EN41B, EN43B, EN47, EN353, IS2062, 42Crmo4, HCHCR, D2, D3, H-11, H-13, CW-1, OHNS, M2, M35, M42, DIN1.2714, P20, P20+S, P20+Ni,  SCM420, ASTMSA-36, ASTMSA-105, SAE1018, SAE4140, SAE8620, 16MNCR5, 20MNCR5, C20, C45, C50, C60, CK45, 20C8, 40C8, 45C8, 55C8, C55MN75, SAE52100, S40C, S355J2G3.

Our Supply Range:

Price List:

People also search as:

ASTM SA-36, ASTM SA-36 Steel, ASTM SA-36 Chemical composition, ASTM SA-36 Mechanical properties, ASTM SA-36 Equivalent Grades, ASTM SA-36 Steel plate, ASTM SA-36 Steel sheet, ASTM SA-36 Manufacturers, ASTM SA-36 Suppliers, ASTM SA-36 Dealers, ASTM SA-36 Stockist, ASTM SA-36 Distributors, ASTM SA-36 Wholesalers, ASTM SA-36 Traders.

Chemical composition:

The following table shows the chemical composition of ASTM SA-36 steel:

Element	C	Cu	Fe	Mn	P	Si	S
Content (%)	0.25-0.29	0.20	98.0	1.03	0.040	0.280	0.050

Mechanical Properties:

Mechanical Properties	Metric	Imperial
Tensile Strength, Ultimate	400 – 550 MPa	58000 – 79800 psi
Tensile Strength, Yield	250 MPa	36300 psi
Elongation at Break (in 200 mm)	20.0 %	20.0 %
Elongation at Break (in 50 mm)	23.0 %	23.0 %
Modulus of Elasticity	200 GPa	29000 ksi
Bulk Modulus (typical for steel)	140 GPa	20300 ksi
Poissons Ratio	0.260	0.260
Shear Modulus	79.3 GPa	11500 ksi

Hardness:

119 – 159

Heat treatment:

1614°C – 1599°C

Hardening:

Hardening at 788°C – 816°C(1450°F-1500°F)

Tempering:

A36 is low carbon steel, it is not suited for heat treatment. So can’t harden. If need hardening, heat to 880-910°C, then quenching in water and temper.

Physical Properties:

Physical Properties	Metric	Imperial
Density	7.85 g/cm3	0.284 lb/in3

Thermal Properties:

Thermal Conductivity, W/m-K   –   50 – 42

Thermal Expansion, µm/m-K   –  11 to 13

Forging Properties:

Preheat slowly, then increase the temperature more rapidly to forging temperature. Then cool slowly

Stress Reliving:

Stress relieving at 677°C – 927°C(1250°F-1700°F)

Normalizing:

Normalizing at 899°C – 954°C (1650°F-1750°F)

Annealing:

Annealing at 843°C – 871°C(1550°F-1600°F)

Density:

Density

7.85 g/cm3

0.284 lb/in3

Machinability:

The machinability rate of ASTM  SA36 is estimated to be 72%, and the average surface cutting feed of ASTM  SA36 is 120 ft/min. Machining of ASTM  SA36 steel is not as easy as that of AISI 1018 steel.

Welding:

ASTM  SA36 steel is easy to weld using any type of welding method, and the welds and joints so formed are of excellent quality.
