C-60

C60 carbon steel is an unalloyed medium carbon engineering steel that has 0.57%-0.65% Carbon as per EN10083 standard. It has characteristics similar to that of C55 carbon steel which has high hardness and high strength after hardening. C60 is difficult to weld, and machinability is poor due to high carbon content. This steel is generally supplied in an untreated or normalized condition.

Grade Application:

C60 carbon steel is an unalloyed heat treatable steel. It is mainly used for parts of mechanical and vehicle engineering. A typical application such as wheels, rims, toothed shafts, cylinders, shafts, axles, pins, screwdrivers, pliers, and similar items

Equivalent grades:

USA	UK	China	Japan	Australia
1060	070M60	60#	S60C	1060

Addition to other grades:

MS, EN1A, EN3B, EN8, EN8D, EN9, EN19, EN24, EN31, EN32B, EN36C, EN41B, EN43B, EN47, EN353, IS2062, 42Crmo4, HCHCR, D2, D3, H-11, H-13, CW-1, OHNS, M2, M35, M42, DIN1.2714, P20, P20+S, P20+Ni,  SCM420, ASTMSA-36, ASTMSA-105, SAE1018, SAE4140, SAE8620, 16MNCR5, 20MNCR5, C20, C45, C50, C60, CK45, 20C8, 40C8, 45C8, 55C8, C55MN75, SAE52100, S40C, S355J2G3

Our Supply Range:

Price List:



Chemical composition:

The following table shows the chemical composition of C60 steel:

Grade	C	Mn	P	S	Si	Cr	Mo	Ni	Cr+Mo+Ni
C60/1.0601	0.57-0.65	0.60-0.90	≤ 0.045	≤ 0.045	≤ 0.4	≤ 0.4	≤ 0.1	≤ 0.4	≤ 0.63
C60E/1.1221	0.57-0.65	0.60-0.90	≤ 0.03	≤ 0.035	≤ 0.4	≤ 0.4	≤ 0.1	≤ 0.4	≤ 0.63
C60R/1.1223	0.57-0.65	0.60-0.90	≤ 0.03	0.02-0.04	≤ 0.4	≤ 0.4	≤ 0.1	≤ 0.4	≤ 0.63

Mechanical Properties:

Mechanical properties at room temperature in the quenched and tempered condition (+QT)
Diameter d mm	≤ 16	16-40	40-100
Thickness t mm	< 8	8-20	20-60
Yield Strength Mpa	≥580	≥520	≥450
Tensile Strength Mpa	850-1000	800-950	750-900
Elongation, %	≥11	≥13	≥14
Reduction of area ,%	≥25	≥30	≥35

Mechanical properties at room temperature in the normalized condition (+N)
Diameter d mm	≤ 16	16-100	100-250
Thickness t mm	≤ 16	16-100	100-160
Yield Strength Mpa	≥380	≥340	≥310
Tensile Strength Mpa	≥710	≥670	≥650
Elongation, %	≥10	≥11	≥101

Hardness:

Heat treatment:

Hardening:

• Hardening:810 – 850°C, water or oil quench

Tempering:

• Tempering:550 – 660°C, Cooling in air

Physical Properties:

Physical Properties	Metric	Imperial
Density	7.85 g/cm3	0.284 lb/in3

Thermal Properties:

Forging Properties:

C60 steel forging temperature:900 – 1100°C, cooling as slowly as possible in the sand after forged.

Stress Reliving:

Normalizing:

820 – 880°C, Cooling in air.

Annealing:

680 – 710°C, Cooling in the furnace.

Density:

Density

7.85 g/cm3

0.284 lb/in3

Machinability:
